| Quantity: | |
|---|---|
ZT916
ZT. MACHINE
Product Advantages
ZT916-specific configuration optimized for balanced lifting performance and low fuel consumption.
Easy operation control layout and robust hydraulic system for smooth bucket cycles and steady dump height.
Versatile 0.5m³ bucket with tooth/non-tooth options, suitable for soil, gravel and aggregate handling.
Compact exterior profile (5470 mm length) makes it suitable for urban jobs and greenhouse/agricultural sites.
Description | Specification |
rated load(kg) | 1000 |
Rated bucket capacity（m³） | 0.5 |
Equipment weight（kg) | 3200 |
Max.dump height（MM） | 3960 |
Max.dump reach（MM） | 840 |
Unloading height(MM) | No teeth 3100 |
With teeth 3020 | |
steering angle（°） | 35 |
Min turning radius（MM） | 4800 |
Wheel base（MM） | 2050 |
Tread（MM） | 1370 |
Min.ground clearance（MM） | 230 |
Overall dimensions (l×w×h)mm（MM） | 5470×1635×2700 |
travel speed（km/h） | |
Forward gear I | 0～6 |
II | 0～18 |
reverse gear I | 0～6 |
II | 0～18 |
Engine Model | Xinchai490 |
Type | Water injection four-stroke inline |
Rated power（kW） | 32 |
Rated speed（rpm） | 2200 |
The voltage(V) | 12 |
Product Details
The ZT916 loader is a compact front end loader engineered around practical site needs. Rated for a 1000 kg load and equipped with a 0.5m³ bucket, this compact front end loader merges maneuverability and dependable lifting capacity. With an overall size of 5470×1635×2700 mm and a min turning radius of 4800 mm, the machine accesses constrained sites efficiently. Travel speed options (two gears) allow operators to adapt to transport or work modes. Keywords: ZT916 loader, compact front end loader, small wheel loader.
Powertrain: Powered by the Xinchai490 engine (32 kW), the ZT916 maintains stable torque for loading cycles while keeping maintenance costs low. The hydraulic and transmission combination yields responsive control during bucket dumping and precise grading tasks. Tyre spec 12-16.5 and a 2050 mm wheelbase ensure firm traction on uneven ground. The loader supports a variety of light attachments for pallet forks or bale spears, expanding its utility on farms and rental fleets.
Use-cases & benefits: As a small wheel loader, the ZT916 is ideal for landscaping contractors, municipal maintenance teams and small-scale construction projects. Max dump height of 3960 mm allows direct discharge into trucks and hoppers. Operator comfort and serviceability were prioritized in the design — daily checks and routine servicing are straightforward, reducing fleet downtime and total cost of ownership.
Client Visit
